IRF540N / IRFZ44N N-channel power MOSFET (TO-220) pinout
← All pinouts · Transistors and MOSFETs
Click the image to open it full size.
Notes
The metal tab is the DRAIN. These need about 10 V on the gate to switch fully, so they are not logic-level. See the IRLZ44N for 5 V drive.
