TIP120 / TIP122 NPN Darlington transistor (TO-220)

TIP120 / TIP122 NPN Darlington transistor (TO-220) pinout

← All pinouts · Transistors and MOSFETs

TIP120 / TIP122 NPN Darlington transistor (TO-220) pinout diagram

Click the image to open it full size.

Notes

The tab is the COLLECTOR. The TIP125 and TIP127 PNP versions use the same pin order.
